Features
SS316 series steam pressure sensor is developed from SS306 series. The sensor capsule is fully welded to the pressure port. No elastic element is used inside. It has good anti-impact and anti-shock ability. Different numbers of cooling fins are integrated between the process connection and housing, acting as a heat sink, which cools the process before it reaches the sensor, extend the maximum process temperature of pressure sensor from 302 °F (150 °C) up to 482 °F (250 °C), with five pcs of cooling extensions, the standard medium working temperature is up to 150°C, 10 pcs is 200°C, and 15 pcs is 250°C.
SS316 series with cooling fins for measuring the pressure of high-temperature steam, such as sterilizing autoclaves, food processing, and power generation. The whole product is produced through components making, semi-finished product, and all-finished product strict testing and aging. It has a stable and reliable performance.
Parameters
Performance
| Accuracy @ 25 °C | ± 0.5% F.S. (incl. non-linearity, hysteresis and repeatability) |
|---|---|
| Non-linearity BFSL (conformity) | ± 0.3% F.S. |
| Hysteresis and repeatability | ± 0.1% F.S. |
| Pressure range | Minimum range: 0.1 bar |
| Maximum range: 1000 bar | |
| Pressure type | vented gauge, sealed gauge, absolute |
| Overload pressure | 2.0 × F.S. (≤ 250 bar) |
| 1.5 × F.S. (> 250 bar) | |
| 1.2 × F.S. (1000bar) | |
| Response time | < 4 ms |
| Long term stability | ≤ 0.2% F.S./Year |
| Temperature coefficient | ± 0.03% F.S./°C |
| Sensor | Silicon |
Electrical specifications
| 4-20mA | 10%-90% | 0-5V / 0-10V | 0.5-4.5V | |
|---|---|---|---|---|
| Supply voltage | 9-30V | 5V ratiometric | 12-30V | 5Vdc |
| Polarity protected | yes | yes | yes | yes |
| Short-circuit protected | yes | yes | yes | yes |
| Zero and span adjustment | No | No | No | No |
| Surge protection | yes | yes | yes | yes |
Environmental conditions
| Medium temperature range | -20°C → +150°C | 200°C, 250°C is on request |
|---|---|---|
| Ambient temperature range | -20°C → +80°C (depending on electrical connection) | |
| Compensated temperature range | 0°C → +70°C | |
| EMC – Emission | EN 61000-6-3 | |
| EMC – Immunity | EN 61000-6-1 | |
| Insulation resistance | > 100 MΩ at 250 V | |
Mechanical characteristics
| Diaphragm | Stainless steel 316L (wetted parts) | Tantalum, Hastelloy-C is on on request | |
|---|---|---|---|
| Enclosure | Stainless steel 304 | ||
| O-ring | FKM / Viton | EPDM is on request | |
| Weight | 0.15 – 0.3 kg (depending on pressure connection and electrical connection) | ||
| Pressure connection | G 1/4″, G 1/2″, 1/4″ NPT, 1/2″ NPT, M20 × 1.5, M14 × 1.5 | Others are on request | |
| Electrical connection | DIN43650, Cable outlet, LED display, M12 × 1 | Others are on request | |
