Features
SS302 series vacuum pressure sensor is the basic product in SENDO and the most widely used one. It follows the piezoresistive principle. The standard medium working temperature is from -20 to 100 °C. A modular concept uses the selection of off-the-shelf capsules, allowing customized production. A lot of options and variants are available. Therefore, it thoroughly adapts to customer requirements: power supply, signal outputs, mechanical and electrical interface, ports, materials in media contact, oil filling, special features, etc.
SS302 series adopts a high-performance pressure sensor as the sensing part. The inner structure is O-ring sealed. It offers a wide temperature compensation range of 0 to 70°C. It is suitable for precision applications in industrial environments for pressures ranging from 0.1 to 1000 bar, liquids, or gases.
Parameters
Performance
| Accuracy @ 25 °C | ± 0.5% F.S. (incl. non-linearity, hysteresis and repeatability) |
|---|---|
| Non-linearity BFSL (conformity) | ± 0.3% F.S. |
| Hysteresis and repeatability | ± 0.1% F.S. |
| Pressure range | -1 to 0 bar, 0 to 0.1 … 1000 bar |
| Pressure type | vented gauge, sealed gauge, absolute |
| Overload pressure | 2.0 × F.S. (≤ 250 bar) |
| 1.5 × F.S. (> 250 bar) | |
| 1.2 × F.S. (1000bar) | |
| Response time | < 4 ms |
| Long term stability | ≤ 0.2% F.S./Year |
| Temperature coefficient | ± 0.03% F.S./°C |
| Sensor | Silicon |
Electrical specifications
| 4-20mA | 0-10V | 0-5V/0.5-4.5V | 0.5-4.5V | |
|---|---|---|---|---|
| Supply voltage | 12-30V | 12-30V | 12-30V | 5Vdc |
| Polarity protected | yes | yes | yes | yes |
| Short-circuit protected | yes | yes | yes | yes |
| Zero and span adjustment | No | No | No | No |
| Surge protection | No | No | No | No |
Environmental conditions
| Medium temperature range | -20°C → +100°C |
|---|---|
| Ambient temperature range | -20°C → +80°C (depending on electrical connection) |
| Compensated temperature range | 0°C → +70°C |
| EMC – Emission | EN 61000-6-3 |
| EMC – Immunity | EN 61000-6-1 |
| Insulation resistance | > 100 MΩ at 250 V |
Mechanical characteristics
| Diaphragm | Stainless steel 316L | Tantalum, Hastelloy-C is on on request | |
|---|---|---|---|
| Enclosure | Stainless steel 304 | ||
| O-ring | FKM / Viton | EPDM is on request | |
| Weight | 0.15 – 0.3 kg (depending on pressure connection and electrical connection) | ||
| Pressure connection | G 1/4″, G 1/2″, 1/4″ NPT, 1/2″ NPT, M20 × 1.5, M14 × 1.5 | Others are on request | |
| Electrical connection | DIN43650A, 9.4 mm mini DIN, LED display | Others are on request | |
Drawings
Electrical connector and housing (Dimensions in mm)
Pressure connection (Dimensions in mm) | Contact us for more options
 |
 |
 |
 |
||||
|---|---|---|---|---|---|---|---|
| G 1/4 inch | L=16.5 mm | 1/8 in NPT | L=13 mm | G 1/8 inch | L=13 mm | G 3/4 inch | L=18.5 mm |
| G 1/2 inch | L=16.5 mm | 1/4 in NPT | L=15 mm | M 10 x 1 | L=13 mm | ||
| M 14 x 1.5 | L=16.5 mm | 1/2 in NPT | L=15 mm | 7/16-20 UNF | L=15 mm | ||
| M 20 x 1.5 | L=16.5 mm | 9/16-18 UNF | L=15 mm | ||||
