Features
SS306 series analog pressure sensor is designed by piezoresistive sensing technology. The pressure sensor cell is laser welded with a process connection. A complete welding structure without an O-ring prevents leaks. It also makes the sensor tough against mechanical shock and vibration. This compact pressure sensor is strong and stable for long-term use. It works well for critical industrial applications and tough media. It includes high-temperature steam, ammonia, acetone, freon, and other refrigerants. Various electrical connections and pressure ports simplify the adaptation to different applications. The attractive price level of the sensor makes it ideal for OEM applications.
Parameters
Performance
| Accuracy @ 25 °C | ± 0.5% F.S. (incl. non-linearity, hysteresis and repeatability) |
|---|---|
| Non-linearity BFSL (conformity) | ± 0.3% F.S. |
| Hysteresis and repeatability | ± 0.1% F.S. |
| Pressure range | -1 to 0 bar, 0 to 0.1 … 1000 bar |
| Pressure type | vented gauge, sealed gauge, absolute |
| Overload pressure | 2.0 × F.S. (≤ 250 bar) |
| 1.5 × F.S. (> 250 bar) | |
| 1.2 × F.S. (1000bar) | |
| Response time | < 4 ms |
| Long term stability | ≤ 0.2% F.S./Year |
| Temperature coefficient | ± 0.03% F.S./°C |
| Sensor | Silicon |
Electrical specifications
| 4-20mA | 10%-90% | 0-5V / 0-10V | 0.5-4.5V | |
|---|---|---|---|---|
| Supply voltage | 9-30V | 5V ratiometric | 12-30V | 5Vdc |
| Polarity protected | yes | yes | yes | yes |
| Short-circuit protected | yes | yes | yes | yes |
| Zero and span adjustment | No | No | No | No |
| Surge protection | yes | yes | yes | yes |
Environmental conditions
| Medium temperature range | -40°C → +100°C |
|---|---|
| Ambient temperature range | -20°C → +80°C (depending on electrical connection) |
| Compensated temperature range | 0°C → +70°C |
| EMC – Emission | EN 61000-6-3 |
| EMC – Immunity | EN 61000-6-1 |
| Insulation resistance | > 100 MΩ at 250 V |
Mechanical characteristics
| Diaphragm | Stainless steel 316L (wetted parts) | Tantalum, Hastelloy-C is on on request | |
|---|---|---|---|
| Enclosure | Stainless steel 304 | ||
| O-ring | All stainless steel welding structure, no o-ring used inside | ||
| Weight | 0.15 – 0.3 kg (depending on pressure connection and electrical connection) | ||
| Pressure connection | G 1/4″, G 1/2″, 1/4″ NPT, 1/2″ NPT, M20 × 1.5, M14 × 1.5 | Others are on request | |
| Electrical connection | DIN43650, Cable outlet, LED display, M12 × 1 | Others are on request | |
Drawings
Electrical connector and housing (Dimensions in mm)
Pressure connection (Dimensions in mm) | Contact us for more options
 |
 |
 |
 |
||||
|---|---|---|---|---|---|---|---|
| G 1/4 inch | L=16.5 mm | 1/8 in NPT | L=13 mm | G 1/8 inch | L=13 mm | G 3/4 inch | L=18.5 mm |
| G 1/2 inch | L=16.5 mm | 1/4 in NPT | L=15 mm | M 10 x 1 | L=13 mm | ||
| M 14 x 1.5 | L=16.5 mm | 1/2 in NPT | L=15 mm | 7/16-20 UNF | L=15 mm | ||
| M 20 x 1.5 | L=16.5 mm | 9/16-18 UNF | L=15 mm | ||||
