Flush Diaphragm Pressure Transmitter Features
SS114 series flush diaphragm pressure transducer with cooling extensions integrated is designed for high-temperature applications; with three pcs of cooling fins, the working temperature can be up to 150°C, six pcs is up to 200°C and the maximum eight pcs can go up to 240°C.
SS114 series is designed by piezoresistive sensor technology for where a flush face is required for easier cleaning. 316L stainless steel housing protects the silicon chip, and silicone oil fills the isolated housing. The transducers can test various media. Typically for use in food, process, and industrial applications where the media is either viscous or is otherwise liable to block the port of a conventional pressure transducer with a recessed diaphragm or pressure port.
Pressure ranges (Typical)
Vented gauge(set the atmospheric pressure as reference) (Unit: bar)
| Range | -1 to 1 | -1 to 5 | 0 to 2.0 | 0 to 4.0 | 0 to 6.0 | 0 to 10 |
| 0 to 16 | 0 to 25 |
Absolute(set absolute vacuum as reference) (Unit: bar)
| Range | 0 to 2.0 | 0 to 4.0 | 0 to 6.0 | 0 to 10 | 0 to 16 | 0 to 25 |
| 0 to 40 | 0 to 60 | 0 to 100 | 0 to 160 | 0 to 250 | 0 to 400 |
Sealed gauge(set standard atmospheric pressure as reference) (Unit: bar)
| Range | 0 to 10 | 0 to 16 | 0 to 25 | 0 to 40 | 0 to 60 | 0 to 100 |
| 0 to 160 | 0 to 250 | 0 to 400 | 0 to 600 |
Flush Diaphragm Pressure Transmitter Parameters
Specifications
| Power supply | 1.5 mA DC (typical) | 5 Volt DC, 10 Volt DC is on request |
|---|---|---|
| Zero output | 0 ± 2 mV | |
| Span output | 100 ± 20 mV (typical) | |
| Accuracy | 0.25% F.S. (typical) | |
| Overload | 2.0 × F.S. (< 250 bar) | |
| 1.5 × F.S. (≥ 250 bar) | ||
| Temperature compensation | 0 to 70 °C | |
| Operating temperature | -20 to 150 °C (typical) | 200 °C, 240 °C is on request |
| Storage temperature | -40 to 125 °C | |
| Zero thermal error | ≤ 0.02% F.S./°C | |
| Sensitivity thermal error | ≤ 0.02% F.S./°C | |
| Bridge resistance | 2.3 to 4 KΩ | |
| Insulation | 100MΩ/250VDC | |
| Vibration | 20g/(20 to 5000Hz) | |
| Endurance | > 100 × 106 F.S. cycles | |
| Stability | ≤ 0.2% F.S./Year | |
Constructions
| Wetted parts | Stainless steel 316L | Diaphragm: Tantalum, Hastelloy-C is on on request |
|---|---|---|
| Housing | Stainless steel 304 | |
| Filling liquid | Silicone oil | |
| Electrical connection | 10 cm silicone sheathed wires | Kovar pins is on request |
| Pressure connection | G1/2″ | Other connection is on request |
Flush Diaphragm Pressure Transducer Drawings
Dimensions
 |
pressure connection | SW | cooling extension | H |
| G 1/2 inch | 27 mm | 3 pcs | 63 mm | |
| G 3/4 inch | 32 mm | 3 pcs | 67 mm | |
| 1/2 inch NPT | 27 mm | 3 pcs | 63 mm | |
| 3/4 inch NPT | 32 mm | 3 pcs | 67 mm | |
| M20 x 1.5 | 27 mm | 3 pcs | 63 mm | |
| G 1/2 inch | 27 mm | 6 pcs | 68 mm | |
| G 3/4 inch | 32 mm | 6 pcs | ||
| 1/2 inch NPT | 27 mm | 6 pcs | 68 mm | |
| 3/4 inch NPT | 32 mm | 6 pcs | ||
| M20 x 1.5 | 27 mm | 6 pcs | 68 mm | |
| G 1/2 inch | 27 mm | 8 pcs | 75 mm | |
| G 3/4 inch | 32 mm | 8 pcs | ||
| 1/2 inch NPT | 27 mm | 8 pcs | 75 mm | |
| 3/4 inch NPT | 32 mm | 8 pcs | ||
| M20 x 1.5 | 27 mm | 8 pcs | 75 mm |
Flush Diaphragm Pressure Transducer Electrical Connections
| wires connection | pins connection | ||||
|---|---|---|---|---|---|
| Color | Function |  |
PIN1: Supply + | ||
| Red | Supply + | PIN2: Output – | |||
| Black | Supply – | PIN3: Supply – | |||
| White | Output + | PIN4: Supply – | |||
| Blue | Output – | PIN5: Output + | |||
